INSTALLATION
Paper Shredder
Operating Instructions
Installation
Operation
Maintenance
Troubleshooting
Warning
* ONE FOLDED SHEET OF PAPER EQUATES TO 2 SHEETS OF PAPER
Heavier paper, humidity or other than rated voltage may reduce shredding capacity.
Mount the shredder securely to the rim of the waste basket (FIGURE 1).
A socket-outlet should be near the equipment and be easily accessible.
Connect the power cord to any standard 220-240 volt AC outlet.
FIGURE 1
This model includes a built-in safety interlock mechanism, which requires the shredder to be
correctly mounted on to the included wastebasket. Located on the back center of the shredder,
next to the power cord, there is a curved flap-like shape that must FIT OVER THE OUTSIDE
matching ridge of the wastebasket (FIGURE1). THE SHREDDER WILL NOT OPERATE UNLESS
IT IS PROPERLY MOUNTED AS PICTURED!
It is not designed to operate with any other wastebaskets. An activation switch located on the
head unit automatically shuts o the shredder when it is lifted or removed. The supplied waste-
basket activates this switch, which allows the shredder to be operable. Lining the wastebasket
with a plastic bag will interfere and may keep the shredder from functioning.
Caution: Crosscut shredders have very sharp exposed blades on the underside.
Use care when mounting the shredder on the wastebasket.
Sheet Capacity 12 sheets of 70 gsm paper*
Paper Shred Size Shreds paper into 5.6 x 55 mm pieces
Shreds CDs into 4 pieces at 35 mm wide
Paper Entry Width 220 mm
Voltage 220-240V/50-60Hz 1.2A
Credit Card / Only one per pass
CD Capacity
OPERATION
FIGURE 2
FIGURE 3
FIGURE 4
Using the switch located on the unit, select one of the following settings by sliding the switch
either left or right (FIGURE 2).
AUTO / ON:
This setting allows the shredder to be automatically started by inserting paper into the shred
opening. Always feed the paper in as straight as possible. When the paper has passed
through, the shredder will automatically stop (FIGURE 2).
OFF:
This setting turns o all features of the shredder. For safety reasons, we recommend that
you leave the shredder in the “O” position whenever the shredder is unattended or not in
use (FIGURE 2).
REV (REVERSE):
In the unlikely event of a paper jam, the reverse setting can be used to help clear the cutters
of paper that has not passed through. Never attempt to clear a jam by using the reverse
function until you have emptied the wastebasket (FIGURE 2).
I
O
R
CONTINUED NEXT PAGE
