8
Technical Specications
Model Standby UPS 400VA 255W, 6 Outlets
Capacity 400 VA / 255 W
Brownout Transfer 96 VAC typical
Over-Voltage Transfer 140 VAC typical
Nominal Input Voltage 120 VAC
On-Battery Output Voltage 120 VAC ± 8 %
On-Battery Output Frequency 50/60 Hz ± 1 %
Transfer Time 8 ms Typical
Max. Load for UPS Outlets
(3 Outlets)
400 VA / 255 W
Max. Load for Full-Time Surge
Protection outlets (6 Outlets)
10 Amps
On-Battery Output Wave Form Simulated Sine Wave
Operating Temperature + 32 °F to 104 °F / 0 °C to 40 °C
Operating Relative Humidity 0 to 95 % non-condensing
Size (L x W x H) 7.2 x 4.3 x 3.2 in. (184 x 110 x 82 mm)
Net Weight 3.59 lbs (1.63 kg)
Typical Battery Recharge Time 8 hours typical from total discharge
Typical Battery Life
3 to 6 years, depending on number of discharge/
recharge cycles
Recommended Battery Sealed Maintenance Free Lead Acid Battery
Safety Approvals UL, cUL, FCC Class B, ICES-003: Class B, CEC
System Function Block Diagram
Input
Output
EMI Filter
Battery Inverter
Surge
Suppressor
Charger
AC / DC
Normal Mode
Battery Mode
