3.3 Individual connection without backup amplier
using ABT-CU-11LT / ABT-CU-11LCD
Individual connection of each of the amplier channels with control cards without backup amplier.
Fig. 10.
POWER SUPPLY MANAGER
ABT-PSM48
ADDRESS
Audio OUT4 Audio OUT3 Audio OUT2 Audio OUT1
0
5
9
4
8
3
7
2
6
1
RS485PSM AUDIO OUT
Local Audio IN
Local Audio OUT 1-4
RS485
Channel 4 IN
Channel 3 IN
Channel 2 IN
Channel 1 IN
ABT-ISLE
ABT-CU-11LT
ABT-PA8080B
Amplier individual connection with ABT-CU-11LT / ABT-CU-11LCD
