ambient SYSTEM ABT-CU-8LCD User Manual

15
3.4 Connection with 100V internal buses
using ABT-CU-11LT / ABT-CU-11LCD
Fig. 11.
POWER SUPPLY MANAGER
ABT-PSM48
ADDRESS
Audio OUT4 Audio OUT3 Audio OUT2 Audio OUT1
0
5
9
4
8
3
7
2
6
1
RS485PSM AUDIO OUT
Local Audio IN
Local Audio OUT 1-4
RS485
Channel 4 IN
Channel 3 IN
Channel 2 IN
Channel 1 IN
ABT-ISLE
ABT-CU-11LT
ABT-PA8080B
Connection with amplier redundant channels using ABT-CU-11LT / ABT-CU-11LTLCD
