Data communication
Communication between devices over large distances:
Ű 1000BASE-X on the ber
Ű 2 ports provide a redundant connection
Communication between devices installed side by side
Ű 1000BASE-TX / RJ45 CAT5E cables –
2 ports available on the back panel.
Ű 100BASE-TX / RJ45 CAT5 cables –
1 port available on the rear panel
for connection to an external network (see notes)
Ű 100BASE-TX / RJ45 CAT5 cables – 1 port available
on the front panel (the main processor card)
forconnection to an external network
Fiber module – connector
type / kind of ber
Modules type SFP / Connector SC/LC /
Multimode or single-mode / E 30 or E 90, OM lub OM2
Communication with PC
PC software: RJ45 connector twisted pair
connection TIA / EIA 568-B
bytheEthernet protocol
Operating temperature 0°C / +60°C
Operating humidity 15% to 80% (non-condensing)
Storage temperature -20°C / +70°C
Storage Humidity 15% to 80% (non-condensing)
Finish Case Material
Finish Case Material: Steel
The front panel is made of metal plate painted black
Dimensions 482 (W) × 85 (H) × 325 (D) mm
Mounting 19˝ – rackmount
Weight Up to 8,4 kg (depends on conguration)
Accessories 2 brackets and 4 screws for rack, 8 caps for free slots
