How Your EASYHEAT Works
19
A
MBRELL
801
-
9526
-
00.doc
Precision Induction Heating
Do this... Observe...
 open water-valve for the system check drain; ensure water is flowing
 check the work-coil ensure there is no work-piece yet
 check condition of (any) safety
barriers or limit switches
all safety devices are clear, electrically
closed
 turn on EASYHEAT AC Power and Ready LEDs (are ON)
  note display:
ensure Setpoint is selected (example)
 press ▲, adjust until:
100A
Within the Home zone, use these buttons to adjust Setpoint and Timer
(indicated with the display pointer ►); press once to make a single-step
adjustment, or you can hold the button to scroll quickly to a new value.
 press ▲, adjust until:
10.00s
  secure unheated part in coil
part not contacting coil; do not hold
 press START
HeatOn, Ready
Ready only, when timer expires (HeatOff
 remove heated part from coil avoid contact with heated portions
  secure unheated part in coil
part not contacting coil; do not hold
  press START
HeatOn, Ready
 press STOP
Ready only
Press START to begin induction heating (Home zone only)
Press STOP to halt induction heating (2-button start type, below). STOP
signal from front or rear panel always halts induction heating.
 remove heated part from coil avoid contact with heated portions
Timed heating…
In this example, you heat the part at 100A output for 10 seconds.
Do this... Observe...
 press ►, select Timer
Untimed
Button is used to move the display pointer from one data field to the next.
