Technical Information
51
MBRELL
-
-
Precision Induction Heating
chdr #
Sets the number of data lines between header lines. Example
will place a descriptive header line every 25 replies when
using the CDATA or CTEMP commands. The value range is 1
to 254. The default setting is 1 data line between headers.
1,chdr,25
chrdata none
Continuous raw data while the heat is on. Same format as
crdata.
1,chrdata
config none
Returns the configuration of the power supply including all
user settings and heat station settings.
1,config
crdata none
Continuous raw data. Same format as rdata, see rdata for
descriptions.
1,crdata
crtemp none Continuous raw temperature data while the heat is on 1,crtemp
ctap #
Changes selected RF transformer tap. Note: Tap must be
physically moved by the user to match the selected tap
setting.
Typing “1,ctap” with no argument will return the current tap
setting.
1,ctap,42
ctemp none
Returns continuous temperature of heat sink and power
supply with a descriptive header line. The header line rate can
be changed using the CHDR command. The interval of
response time can be set using the CTIME command.
1,ctemp
ctime #
Example will set the system to send a response every
500msec. 1=100msec. The variable can be 1 to 65534. This is
used for CDATA, SLCDATA, RDATA, SLRDATA, CTEMP and
SLCTEMP commands. The default is “2” for 200mSec.
1,ctime,5
ctl-
filea/b/c/d
Selects a profile to load and run. Example select profile B.
Selectable profiles are A, B, C and D.
1,ctl-fileb
ctl-fpan none Selects control to be front panel. 1,ctl-fpan
ctl-rpan0-10 none Selects control to be rear panel 0-10V analog input. 1,ctl-rpan0-10
ctl-rpan4-20 none
Selects control to be rear panel 4-20ma analog input. Note: 4-
20 rear panel jumper must be in correct location.
1,ctl-rpan4-20
ctl-rs485 none Selects control location to be RS485. 1,ctl-rs485
ctrloff none Turns off RS485 keyboard control of set point. 1,ctrloff
ctrlon none
Enables RS485 control of set point. Use "]" right bracket key
to increase set point. Use "[" left bracket key to lower set point.
1,ctrlon
data none
Multi-line single reply, PS address, Heat status, Setpoint,
Amps output, Frequency and Timer setting.
1,data
hoff
none
Heat off command. Will turn heat off regardless of start from
location selection.
1,hoff
hon
none
Heat on command. Will turn heat on if start from RS485 is
selected.
1,hon
hst none Returns the heat station configuration. 1,hst
maxamps
none
Returns the maximum attainable set point in amps based on
the heat station tap setting, heat station maximum current
capability, or the maximum current carrying capacity of the
heat station cable
1,maxamps
pstat none
Returns the previous heat on cycle status messages of the
power supply.
1,pstat
rdata none
Returns raw data only with a comma separating each data
field. The response includes: Address,heat-
status,setpoint,amps-out,frequency,timer,counter
1,rdata
rtemp none
Provides raw temperature data including heat sink and air
temperature.
1,rtemp
