Technical Information
60
Precision Induction Heating
MBRELL
®
-
-
Do this... Observe...
STOP
unit is Ready
turn off AC power switch at rear AC power LED is not lighted
ensure fused disconnect is open to remove all AC
power from the system
use Philips screwdriver to remove power supply cover; retain cover and screws
locate J1,J2 connectors (shown)
to select lower mains range, set:
J1B; J2A
to select higher mains range, set:
J1A; J2B
replace unit cover and secure screws
restore AC power
Navigate to Menu Selection > System Options
select ►AC Voltage
select the new mains range setting
returns to Home zone
Your system has been sealed (circle); if the seal is
damaged, internal mains voltage range settings may have
been changed; verify this setting before connecting to
AC mains power. This label (arrow) indicates sealed
mains voltage range. We provide one set of replacement
seal and voltage range label.
