AMBROGIO A020EL0 - Technical Information; Technical Specifications

6
User’s manual
EN
TECHNICAL INFORMATION
TECHNICAL SPECIFICATIONS
Description
Model
A015DE0 A020DE0 A020EL0
Maximum recommended surface that can be mowed
Working capacity ( -20%(*)) m
2
(ft
2
)
600
(6458)
700
(7534)
1000
(10763)
Features
Dimensions (W x H x D) mm 420x290x220
Robot weight (incl. battery) kg 7,1 7,2
Cutting height (Min-Max) mm (") 25-70 (0,98-2,75")
Diameter of blade mm (") 180 (7,08 ")
Motors without brushes
Cutting blade speed RPM 4200
Ground speed Metres / Minute 28 (91,8 ')
Maximum recommended slope
managed (*)
%
45% allowable, based on the lawn conditions and accessories
installed.
35% maximum managed and recommended in conditions of a
trimmed lawn.
20% in proximity of the outside edge or perimeter wire.
Ambient operating temperature Max °C
ROBOT: -10°(14 F.) (Min) +50° (122 F.) (Max)
CHARGING STATION: -10°(14 F.) (Min) +45° (113 F.) (Max)
BATTERY CHARGER: -10°(14 F.) (Min) +40° (104 F.) (Max)
Measured sound power level dB(A) 57
Water protection class IP
ROBOT: IPx5
CHARGING STATION: IPx4
BATTERY CHARGER: IPx4
Electrical features
Power supply unit (for lithium battery)
SOY-2940230
Input: 100-240 V~; 1.8A; 50/60Hz; Class 1
Output: 29.4V ;
; 2.3A
- Alternative code -
Mean Well OWA-60E-30ZCT
Input: 100-240 V~; 1.2A; 50/60 Hz; Class 2
Output: 29.4V ; 2.0A
Type of accumulator and charging batteries
Rechargeable Lithium-Ion Battery
(rated voltage)
25.9V - 2.5 Ah
Type of charging contact
Average recharging time hh:mm 1:00
Average mowing duration after a full
charge cycle (*)
hh:mm 02:00
(*) Depends on the condition of the grass, lawn and the complexity of the mowing area.
