INSTALLATIONS
Installing the Memory
The MB740 board supports one DDR memory socket for a maximum
total memory of 1GB in DDR memory type.
Installing and Removing Memory Modules
To install the DDR modules, locate the memory slot on the board and
perform the following steps:
1. Hold the DDR module so that the key of the DDR module align with
those on the memory slot.
2. Gently push the DDR module in an upright position until the clips of
the slot close to hold the DDR module in place when the DDR module
touches the bottom of the slot.
3. To remove the DDR module, press the clips with both hands.
MB740 User’s Manual 7
