INSTALLATIONS

8 MB740 User’s Manual

Setting the Jumpers

Jumpers are used on MB740 to select various settings and features

according to your needs and applications. Contact your supplier if you

have doubts about the best configuration for your needs. The following

lists the connectors on MB740 and their respective functions.

Jumper Locations on MB740 .......................................................... 9

JP8: CompactFlash Slave/Master Selection .................................. 10

JP9: 1394 EPROM Write Selection .............................................. 10

JP12: Clear CMOS Setting ........................................................... 10

JP14: RTL8110S-32 LAN Enable / Disable ................................. 10
