BIOS SETUP
MB740 User’s Manual 37
PC Health Status
This section shows the parameters in determining the PC Health Status.
These parameters include temperatures, fan speeds and voltages.
Phoenix - AwardBIOS CMOS Setup Utility
PC Health Status
Shutdown Temperature Disabled
ITEM HELP
Vcore(V) 1.02 V
2.6V
Menu Level >
Vcc3.3V
Vcc5V
+12V
SB 3.3V
-12V
SB 5V
Voltage Battery
CPU TEMP
SYSTEM TEMP
POWER TEMP
SYSTEM FAN Speed
CPU FAN Speed
SmartFAN Disabled
Temperatures/Voltages
These fields are the parameters of the hardware monitoring function
feature of the motherboard. The values are read-only values as
monitored by the system and show the PC health status.
Shutdown Temperature
This field allows the user to set the temperature by which the system
automatically shuts down once the threshold temperature is reached.
This function can help prevent damage to the system that is caused by
overheating.
