Figure 4–1 Connecting the Power Cables
1 Power supply
2 Existing card
3 New card
8. If your AMD CrossFire configuration requires an AMD CrossFire internal bridge
interconnect between cards, remove the protection tags from the ends of the
AMD CrossFire interconnect before using it to connect the cards.
Caution:
Always handle the AMD CrossFire bridge interconnect by the connector only.
Do not push or pull on the flexible cable.
AMD CrossFire™ Technology 13
© 2014 Advanced Micro Devices, Inc. AMD Radeon™ R7 260X Graphics

AMD Radeon R7 260X Specifications

General

GPU Architecture	GCN 1.1
GPU	Bonaire
Stream Processors	896
Core Clock	1100 MHz
Memory Size	2 GB
Memory Type	GDDR5
Memory Bus	128-bit
Memory Clock	1625 MHz
Memory Bandwidth	104 GB/s
Compute Units	14
Texture Units	56
ROPs	16
TDP	115 W
Shader Model	5.0
Process Size	28 nm
Transistors	2.08 billion
Die Size	160 mm²
Power Connectors	1x 6-pin
Outputs	HDMI, DisplayPort
OpenCL	OpenCL 1.2
OpenGL Support	OpenGL 4.3
