Callout No.Ref. Des. Feature Notes Schematic Page
SoC SD 3.0 level
translator circuit
12 U33 I2C bus switches Texas Instruments
TCA9548APWR
IC switch bus 1-In 8-Outs
I2C 400 kHz
Bottom of board
39
13 U233 I2C bus expander Texas Instruments
TCA6416APWR
IC exp. GPIO 16-bit I2C 400
kHz
Bottom of board
39
14 J392,
J393
CAN bus
connectors
Phoenix 1935174
Conn Term Blk RA 3 Pos
1x3 5 mm P 17.5A 250V
Green TH 14-26AWG Screw
Clamp
41
17 J376 zSFP+ connector Molex 1703820001
zSFP+ connector and cage
29
18 J390,
J391
HDMI™ TX and
HDMI RX
connectors
Molex 2086581061
Conn Rcpt HDMI 2.1 RA
44-45
19 J307 GEM0 SGMII
Ethernet PHY,
0x01, RJ45 w/mag
Halo HFJ11-1G01E-L12RL
RJ-45 Gigabit connector
36
20 J51 FMCP1 Samtec ASP-184329-01
560 pos. connector 14x40
1.27 mm
30-34
21 Various Adaptive SoC
power
management
Infineon regulators 51-56
