Callout No.Ref. Des. Feature Notes Schematic Page
(B700-B702 IF) IC SDRAM LPDDR4
512Mx32 2133 MHz
3 U319,
U320
LPDDR4 16 GBIT
comp. memory
(B703-B705 IF)
Micron
MT53E512M32D1ZW-046
IC SDRAM LPDDR4
512Mx32 2133 MHz
4,24,25
4 U321,
U322
LPDDR4 16 GBIT
comp. memory
(B706-B708 IF)
Micron
MT53E512M32D1ZW-046
IC SDRAM LPDDR4
512Mx32 2133 MHz
5,26,27
5 J11 SYSMON header Sullins PBC06DAAN
Conn. hdr. vert. 12 pos. 2x6
2.54 mm pitch
10
6 J36 Adaptive SoC
JTAG 2 mm 2x7
flat-cable
connector
Molex 0878321420
Conn. hdr. male vert. 14
pos 2x7 2 mm
20
7 U298 PCIe® clock buffer Renesas RC19004AGNL 49
8 J378 PMOD 2x6
connector
Sullins PPPC062LJBN-RC
Conn Hdr Female RA 12
Pos 2x6 2.54 mm P TH
48
9 J369,
U20
USB-UART bridge,
USB Type-C
connector
(USB2.0)
Amphenol 12401598E4#2A
FTDI FT4232HL-REEL
21
10 J308,
U99
USB 2.0 type-A
connector, USB
ULPI transceiver
Wurth 629104190121, USB
2.0 type-A
Microchip USB3320C USB
2.0 Xcvr
37
11 J302,
U104
SD card socket,
Versal adaptive
Molex 5025700893
Micro SD card cage
35
