Callout NumberRef. Des. Function Default Schematic Page
17 SW4,
SW5
User pushbutton inputs
Note: Pushbutton switch
default = open = logic low (not
pressed).
Open 48
18 SW6 User GPIO DIP
Switch OFF = 0 = low; ON = 1 =
high
OFF, OFF,
OFF, OFF
48
19 SW12 System controller power-on reset
(SYSCTL_POR_B)
Open 77
20 SW13 Main power OFF 50
21 SW14 User USB reset Open 37
22 SW15 User GEM reset Open 36
23 SW16 System controller FWUEN
pushbutton
(SYSCTLR_MIO12_FWUEN_C2M_B)
See BEAM wiki for more
information
Open 76
Versal Device Configuration
The “Platform Boot, Control, and Status” section of the Versal Adaptive SoC
Technical Reference Manual (AM011) describes the Versal XCVE2802 device boot
process. The VEK280 board supports a subset of the modes documented in the
technical reference manual via onboard boot options. The mode DIP switch SW1
configuration option settings are listed in the following table.
Table: Mode Switch SW1 Configuration Option Settings
Boot Mode
Mode Pins [0:3]
2
Mode SW1 [1:4]
2
JTAG
0000
1,3
ON, ON, ON, ON
OSPI 0001 ON, ON, ON, OFF
