Aries Adapter Pin Number NVT4857UKAZ Pin NumberNVT4857UKAZ Pin Name
8 Unused Unused
9 Unused Unused
10 A3 VSD
11 A2 VCCA
12 Unused Unused
13 D1 DATA0
14 E3 SEL
15 B1 DAT3A
16 E1 DAT1A
17 Unused Unused
18 A1 DAT2A
19 E4 DAT1B
20 D4 DAT0B
21 D3 CLKB
22 C4 CMDB
23 B4 DAT3B
24 A4 DAT2B
25 Unused Unused
The Versal device (U1) also has control over the power for the SDCARD, which
allows the Versal device to remove power to the SD card as needed.
Figure: SD Socket J302 Power Control
