AMD XILINX VEK280 - Page 69

3/20/24, 12:51 PM
Unofficial Document
https://docs.amd.com/internal/api/webapp/print/d54fa025-f5b0-4797-be6e-41b3e31f9548
69/78
Rail Rail Name Nominal Voltage (V)Max Current (A)Device PMBUS AddrINA226 Addr
U277
2 VCC_PMC 0.88 1 U160 A 0x47 0x42
BUS1
3 VCC_RAM 0.80 2 U160 C 0x47 0x43
BUS1
4 VCC_PSLP_CPM5 0.88 6 U175 C,D 0x4D 0x44
BUS1
5 VCC_PSFP 0.88 4 U167 C 0x4C 0x45
BUS1
6 VCC_SOC 0.80 25 U152 L2, U153 0x46 0x41
BUS1
7 VCCAUX 1.50 4 U167 D 0x4C 0x40
BUS1
8 VCCAUX_PMC 1.50 1 U167 B 0x4C 0x41
BUS2
9 VCCO_MIO 1.80 2 U279 D 0x48 0x45
BUS2
10 VCCO_502 1.80 1 U175 B 0x4D 0x47
BUS2
11 VCC1V1_LP4 1.10 6 U279 A, U292 0x48 0x49
BUS2
12 VCC1V5 1.50 2 U279 B 0x48 0x43
BUS2
13 VADJ_FMC 1.50 6 U282 0x4E 0x4A
BUS2
14 LPDMGTYAVCC 0.92 4 U279 C 0x48 0x4B
BUS2
