Ameda Elite User Manual

Cleaning the Ameda Elite Breast Pump
s$ISCONNECTTHEPUMP
power cord from wall
outlet.
s2EMOVEPISTONCYLINDERBY
placing index finger into
the tube, lifting upwards
and turning right to release
from attachment bars.
For At-Home/End-Users
After each pumping, wipe
pump with cloth dampened
with warm, soapy water.
For Hospitals/Rental Stations
Clean between users.
Spray with recommended
disinfectant, such as
CaviCide
TM
. Wipe with soft
cloth. Do not use products
containing phenol.
Do not use bleach on pump.
s0LACEPISTONCYLINDERBACK
onto attachment bars and
press gently into place with
thumb.
Troubleshooting
Pump Does Not Turn ON
s%NSUREPROPERPOWERCORDCONNECTIONTOPUMP
s%NSUREPOWERCORDCONNECTIONTOWALLOUTLET
s%NSUREOUTLETHASPOWER
Low or No Suction
s#HECKBREASTmANGEFORADEQUATESEALAGAINSTBREAST
s#HECKTHATTHE!MEDA(YGIENI+IT-ILK#OLLECTION3YSTEM
is properly assembled.
s#HECKTHATADAPTERCAPISlRMLYSNAPPEDONTOTOPOF
breast flange.
s%NSURESILICONEDIAPHRAGMISINPLACEINSIDETOPOFBREAST
flange.
s%NSURETUBINGADAPTERISPROPERLYlTTEDINTOTUBING
adapter port on pump.
s)NSPECTVALVEFORSTRETCHINGORTEARS)FSEENREPLACE
valve.
s%NSUREVALVEISPUSHEDlRMLYINTOPLACEINLOWERPORTION
of breast flange.
s%NSUREONESIDEOFTUBINGADAPTERISCLOSEDWHENSINGLE
pumping.
Maintenance
It is recommended the Ameda Elite Breast Pump be
inspected at least once every year to include the following:
s6ISUALLYCHECKPUMPHOUSINGFORCRACKSBREAKAGEOR
damage and ensure pump feet are present.
s6ISUALLYCHECKFORPOWERCORDDAMAGE
s#HECKFORPROPEROPERATIONOFCONTROLSANDBUTTONS
s#HECKTHEREARENOMISSINGSCREWS
s#HECKTUBINGADAPTERPORTONPISTONCYLINDERISFREEFROM
obstruction.
Quick Functional Check
The following checks/tests should be performed prior to use
by a new user:
s6ISUALCHECKSFORPOWERCORDDAMAGE
s#HECKFORABNORMALNOISE
s#HECKFORPROPEROPERATIONOFCONTROLS
Replacing Detachable Power Cord IFAPPLICABLE
s0OWERCORDISDETACHABLEFROMPOWERINLET
s)FPOWERCORDCONDITIONISINDOUBTONLYREPLACEWITH
Ameda supplied 2 conductor cord.
Technical Information/ Icon Glossary
Main voltage
Elite with Detachable Power Cord 100VAC to 240VAC
Elite with Built-In Power Cord 100/120V ~ or 220/240V ~ /AC
Frequency 50 / 60 Hz
Power consumption 30 VA
Main fuse T 1.6A
Protection class Class II
Double isolated
Safety level = BF
Drip protection IP 21
Operational conditions
Transport and
Storage conditions
Fragile
Protect from sunlight
Keep Dry
Consult Instructions for Use
Weight 6.4 lbs/2.9 kg
Dimensions 10.0”L x 9.0”W x 7.5”H
22.2cmL x 26.7cmW x 18.4cmH
Vacuum max. [mbar] [mm Hg]
Single HygieniKit  
Dual HygieniKit  
Variable cycle 30 - 60 / Min
Conforming to
ENGLISH 7
130ºF
54ºC
-10ºF
-23ºC
90
20
%
93ºF
34ºC
53ºF
12ºC
70
20
%
Ameda, Inc.
485 Half Day Road
Buffalo Grove, IL 60089
USA
0086
%-%$)#!,%15)0-%.4
WITH RESPECT TO ELECTRIC SHOCK,
&)2%!.$-%#(!.)#!,(!:!2$3/.,9
).!##/2$!.#%7)4(
IEC60601-1: 1988 + A1:1991 + A2:1995,
)%##!.#3!#.O-

Ameda Elite Specifications

General

Suction Levels	Adjustable
Cycle Speed	Adjustable
BPA Free	Yes
Double or Single Pumping	Double
Battery Operated	No
Closed System	Yes
Warranty	1 year
Power Source	AC Adapter
