- 20 -
Specification
Model
LCD Panel 20.1 inch TFT, TN Mode
Display Mode 3D De-interlace
Input Filter 3D Comb filter
Display area 408 x 306mm
Resolution 800 x 600
Brightness 500 cd/m
2
@6mA
Contrast ratio 480:1
Response Time 16ms typ.
L/R View angle
U/D
80(left),80(right),60(up),60(down) CR=10
80(left), 80(right),80(up),80(down) CR=5
Input Signal BNCx2 in
BNC x2 out (Auto Termination)
D-Sub 15pin
Y/C x1 in
Y/C x1 out
Audio In/Out RCA(R/L) x 2 set in
RCA(R/L) x 2 set out
Operating Controls OSD
Power Supply AC 96~256V 50/60Hz
Power Consumption 52W
Dimension 420x406.5x85.2mm
Weight 6.8kg
Temperature
-10~60?
Humidity 20%~80%
