Ameristar 4TXK1609A1 - Connection Pipe Requirements

10
16 Series Mini-Split
Operating Ranges
Cooling Only Operating Range Outdoor Temperature 0 - 115°F (-18.0 - 46.1°C)
Heat Pump Operating Range Outdoor Temperature -4.0 - 75°F (-20.0 - 24°C)
Connection Pipe Requirements
NOTICE
The maximum distance of the connection piping in both height and total length is provided in the
table below. Do not install these units in locations that exceed these specications.
NOTES:
1. The connection pipes should be insulated with proper water-proof insulating material
2. Wall thickness of pipe 0.02-0.04 in (0.5-1.0 mm): bearing pressure 435 PSI (3.0 MPa).
3. Shorter connecting pipe lengths result in greater thermal e󰀩ciency, so it is preferable to reduce
connecting pipe lengths where possible.
4. Refer to the oil trap instructions for specic requirements when there is height di󰀨erence
between the indoor and outdoor unit greater than 20 feet (6m).
Heat Pump
4TXK1609 4TXK1612 4TXK1618 4TXK1624
4MXW1609 4MXW1612 4MXW1618 4MXW1624
Refrigerant Charge (oz.) 24.7 30 49.4 65.3
Standard Length ft (m) 25 (7.6)
Additional Refrigerant Charge (oz/ft)
For Piping Beyond Standard Length
0.2 0.5
Outer Diameter
Liquid Pipe in (mm)
Φ 1/4" (6.35)
Gas Pipe in (mm)
Φ 3/8" (9.52) Φ 1/2" (12.7) 5/8" (15.875)
Max Distance
Height ft (m)
65 (20)
Length ft (m)
100 (30) 130 (40)
Minimum Piping Length ft (m) 10 (3)
Compressor Oil Used DAPHNE FVC50K (PVE Oil) RB68EP (POE Oil)
Cooling Only
4TYK1609 4TYK1612 4TYK1618 4TYK1624
4MYW1609 4MYW1612 4MYW1618 4MYW1624
Refrigerant Charge (oz.) 24.7 30 35.3 56.4
Standard Length ft (m) 25 (7.6)
Additional Refrigerant Charge (oz/ft)
For Piping Beyond Standard Length
0.2
Outer Diameter
Liquid Pipe in (mm)
Φ 1/4" (6.35)
Gas Pipe in (mm)
Φ 3/8" (9.52) Φ 1/2" (12.7) 5/8" (15.875)
Max Distance
Height ft (m)
65 (20)
Length ft (m)
100 (30) 130 (40)
Minimum Piping Length ft (m) 10 (3)
Compressor Oil Used DAPHNE FVC50K (PVE Oil) RB68EP (POE Oil)
