Meter Board (50-0800-3)
Designator Description Ameritron P/N
D301 1N34A 300-0346
C301, 302 .47 uF 50 V tantalum 203-0530
C303, 304, 307 - 311, 314, 315 .1 uF 50 V 200-0754
C305, 306 .001 uF 1 kV 200-2120
R301, 302 2.2M 1/4 W 100-6220
R303 390 ohm 1/4 W 100-0390
R304 2.2k 1/4 W 100-1200
R305 470k 1/4 W 100-0188
R306, 310 10k 1/4 W 100-4100
R307 100 ohm 1/4 W 100-2100
R308, 311 33k 1/4 W 100-3330
R309 4.7k 1/4 W 100-1470
R312 330 ohm 1/4 W 100-0330
R313 270 ohm 1/4 W 100-0600
R316 47k 1/4 W 100-4470
IC301 LM324 311-0324
Q301, 302 2N3904 305-0645
Q303 2N3906 305-0722
S301 Rotary 2P6T 500-0563
Tuned Input Board (50-0800-2)
Designator Description Ameritron P/N
C202 (tube side) See input chart
C201 (transmitter side) See input chart
L201 See input chart
S201 Input switch
AL-800 Tuned Input Chart
S201 BAND Capacitor (pF) Input Inductor Capacitor (pF) Output
1 160 1600, (208-5455), C201 21.75, (405-1217), L201 1300, (208-5177), C202
2 80 1300, (208-5177), C203 18.75, (405-1187), L202 1000, (208-5176), C204
3 40 470, (208-5440), C205
220, (208-5175), C215
10.75, (405-1107), L203 500, (208-5691), C206
4 20/30 330, (208-5331), C207 5.75, (405-1057), L204 330, (208-5331), C208
5 15/17
*
150, (208-5151), C209 3.75, (405-1037), L205 220, (208-5175), C210
6 10/12 100, (208-5174), C211 4.75, (405-1047), L206 68, (208-5395), C212
* 150pF, (208-5151), C214
220pF, (208-5175)
4T Air Coil, L207
