AMERITRON AL-80B - Al-80 B Main Chassis Parts List

AL-80B Instruction Manual
28
Al-80B Main Chassis Parts List
Designation Description Ameritron PN
B1 Blower 410-3138
C1-3 .001 uF 7.5 kV 200-7224
C4 500 pF Doorknob 7.5 kV 210-0470
C5, 6 170 pF Doorknob 7.5 kV 209-0559
C7 Air Variable Plate 204-2112
C8 Air Variable Load 204-2573-1
D1 LED, Red 320-0522-1
F1, 2
See Jumper Connections Chart, (page
Error! Bookmark
not defined.
)
--------------
50-0080-1 Power Supply / SWR Board Assembly 50-0080-1
50-0080-2 Input Circuit Board Assembly 50-0080-2
50-0080-3 Metering Board Assembly 50-0080-3
50-0080-4 RF Tank Board Assembly (only parts L1-L2) 50-0080-4
50-0080-5 Timer-Overload Board Assembly (optional.-See page 27) 50-0080-5
L1 "L " Coil 10-13165
L2 LF Coil (mounted on 50-0080-4) 10-13240
L3 HF Coil (mounted on 50-0080-4) 10-13108
M1 Meter (Forward and Reflected) 400-3581
M2 Meter (grid and plate) 400-3580
R1 1 k pot (ALC limit) 105-1301
R2 100 k pot (ALC SET) 105-1341
RFC1 Parasitic choke 10-15105
RFC2 Plate Choke 10-15197
RFC3 2.5 mH Choke 402-1162
S1 Band Switch 500-2135
S2 Lighted Switch 507-1157
S3 Rocker Switch 507-1150
S4 Interlock Switch 504-3247
R3 33 ohm 1/4 watt 100-1330
Q3 Transistor MJF-3055 305-3055
T1 Transformer 406-1109-2C
V1 3-500Z Tube 350-0167
