AMERITRON AL-80B - Frequency Coverage; Amplifier Tuning Log

AL-80B Instruction Manual
29
Frequency Coverage
AL-80B AL-80BX
160 meters 1.8-2.0 MHz 160 meters 1.8-2.0 MHz
80 meters 3.3-4.4 MHz 80 meters 3.3-4.4 MHz
40 meters 6.3-8.3 MHz 40 meters 6.3-8.3 MHz
20 meters 10.1-15.5 MHz 20 meters 10.1-15.5 MHz
15 meters
16.5-21.5 MHz*
15 meters
16.5-21.5 MHz*
10 meters
24-29 MHz*
* Operation on 11-13 MHz, 15.5-16.5 MHz, and 25-27.9 MHz will damage components.
Amplifier Tuning Log
Band
"LOAD" "PLATE"
160 CW
160 SSB
80 CW
75 SSB
40 CW
40 SSB
30 CW
20 CW
20 SSB
17 CW
17 SSB
15 CW
15 SSB
Fill in this log with the amplifier settings to quickly change bands. Use a pencil as settings may
change with different antennas.
