05/18/2021 27
charge cycle. This value cannot exceed the maxi-
mum charger output rating.
PRESENT MONTH
The month that the charge cycle occurred.
PRESENT DATE
The day of the month that the charge cycle occurred.
EC2000 Charge Cycle Review Function
The review function allows up to 66 items of charge
cycle information to be retrieved and displayed. Only
the last charge cycle is stored, with the data being
moved into archive cycle #1 location when the next
battery is connected to the charger. The review data
functions described in detail below in ascending
order.
A single review item can be accessed by entering its
item number at the “Enter Rev Func # ” prompt.
The following key sequence is used to access charge
cycle review data functions.
Keys Display
Program Enter 1-REV 2-PROG
Function 3-MAH 4-ARCH
1 Enter Rev Func # 01
Key in function number and press enter or scroll using
arrow keys to review entire charge cycle (see Fig. 7-2).
You may re-enter a new function number at any time
to jump through the menu quickly.
01. AMP HOURS RET
The total ampere-hours returned during the charge
cycle. This number includes ampere-hours delivered to
the battery during the Verify, 0-80%, 80% to End, and
Equalize portions of the charge cycle.
02. CHARGE TIME
The total charging time of the charge cycle. This
number includes the time of the Verify, 0-80%,
80% to End, and Equalize portions of the charge
cycle.
03. 80% TO END
The time the battery was charged from the 80%
charged point until DV/DT or VT (depending on the
control setting) charge termination. This time does not
include any Equalize charging time.
04. BATTERY OCV
The open circuit voltage of the battery immediately
before the beginning of the charge cycle.
05. START AMPS
The value of the current delivered to the battery at the
start of the charge cycle.
06. START VOLTS
The value of the battery voltage (in volts/cell) of the
battery at the start of the charge cycle.
07. FINISH AMPS
The value of the charge current delivered to the battery
at the end of the charge cycle.
08. FINISH VOLTS
The value of the battery voltage at the end of the
charge cycle.
09. TERM
The reason for charge cycle termination. All possible
codes are listed below:
1-Charge Comp Normal Charge Complete
2-Low Current Low Current Error shutdown
3-Manual Stop Manual stop
4-Battery Dis Battery disconnected while
charging
5-<80 Backup 0-80% Back-up Timer Error
Shutdown.
9-Curve Error Charger Output Curve Error
Shutdown
10-Overtemperature Excessive Charge
Component Heating
11-Phase Error Unbalanced Input Line Error
Shutdown
12-Didt Rising Current/Falling Voltage
Error shutdown
13-Lvsd Low Charging Voltage Error
Shutdown
14-Ahsd Excessive AH Returned Error
Shutdown
16-Arcless The Arcless circuit is open
10. EQUALIZE TIME
The time of the equalize portion of the charge cycle.
11. START TIME
The time at the start of the charge cycle (military for-
mat).
12. END TIME
The time at the end of the charge cycle. Includes the
equalize time if it was automatically or manually
selected (Military format).
13. CHARGER HEAT SINK TEMPERATURE
The last recorded temperature of the charger power
components heat sink while the charger was
charging.
14. BATTERY I.D.
The Battery I.D. number of the battery that was
charged in the charge cycle. Requires Prestolite
Battery Identification Module (BID).
15. BATTERY VOLTS
The present voltage of the battery connected to the
battery charger (volts DC).
193111-121
EC2000 CONTROL FEATURES
