EC2000 CONTROL FEATURES
16. CYCLE Kwh
The estimated Kilowatt Hour usage for the last
charge cycle.
17.
The temperature of the battery sensed by the Pres-
tolite Battery Identification Module at the start of
the charge cycle (degrees F).
18.
The temperature of the battery sensed by the Pres-
tolite Battery Identification Module at the end of
the charge cycle (degrees F).
19. PRESENT TIME
The present time (military format).
20. WEEK DAY
The present day of week (SUN through SAT).
21.
The type of auto equalize selected. The types that
can be selected are listed below:
CYC. = By cycle count (see AUTO EQ.
COUNT).
D.O.W. = By the day of week (see Auto EQ.
Day).
BID = By BID count
22.
The number of charge cycles between equalize
charges when the auto equalize function is pro-
grammed “ON” and the auto equalize type is set to
“COUNT”.
23. EQ. DAY
The day of the week that an equalize charge cycle is
performed when the auto equalize function is “ON”
and the auto equalize type is set to “DAY”.
24. AUTO EQUALIZE
Shows the auto equalize function on or off.
Auto equalize “OFF”
Auto equalize “ON”
25. T.O.D. START
Time of day start time. (military format). See START
MODE.
26. DELAYED START
Delayed start time interval. (00H 00M to 23H 59M).
See START MODE.
27. BLOCK START
The beginning time of the time of day blockout
function (AM/PM). See START MODE
28. BLOCK END
The ending time of the time of day blockout function.
(AM/PM). See START MODE.
29. START OVERIDE
The start override function that allows the operator to
override any of charger start modes (i.e. delayed
start, time of day start, or time of day blockout) by
pressing the ENTER key.
30. START MODE
Shows the selected start mode for the start of the
charge cycle.
AUTO = Automatic mode
T.O.D.S. = Time of day start mode
DELAYED = Delay start mode
T.O.D.B = Time of day blockout
TIMER = Timer Mode
BMS = BMS Only
31. FORMING CYCLES
The number of forming cycles for a new battery by
disabling the low current shutdown, and setting VT
Termination mode for the programmed number of
cycles (00 to 30).
32. SPECIAL OPTION
Special option modes see below.
OFF
“P.T.S.“ = Push to start mode.
The charger will not start until the “ENTER” key is
pressed.
F.L.O. = Fault lockout mode.
The charger will not restart until any faults are reset
by pressing the “ENTER” key with no battery
connected.
33. CYC. AMP HOURS
The ampere-hour setting of the charger during the
WARNING: Enabling the Finish Cell
Forming feature will cause the
charger to continue to run for a
period of time if the battery has
been disconnected before Charge
Complete or pressing the Manual
Stop key. This condition will continue
until the programmed number of
cycles have been completed. The
battery should never be disconnected
while a charge is in progress.
