05/18/2021 29
charge cycle. This value cannot exceed the maxi-
mum charger output rating.
34. CYCLE CELLS
The cell size setting of the charger during the charge
cycle. This value cannot exceed the maximum
charger output rating.
35. FIXED CELL SIZE
The cell size the charger will operate at if the ”multi-
cell mode” is not selected and the charger does not
detect a Prestolite BID module. See “MULTI-CELL
MODE”.
36. FIXED AMP HRS
The ampere-hour size the charger will operate at if
the charger does not detect a Prestolite BID module.
37. FIX.BAT.TEMP.
The battery temperature used for charger output volt-
age compensation, if the charger does not detect a
Prestolite BID Module (032 to 132°F).
CAUTION: Do Not Exceed the Battery
Manufacturer’s Maximum allowed Battery
temperature.
38. BATTERY TYPE
The battery type the charger uses to select the proper
output voltage and current characteristic, if the
charger does not detect a Prestolite BID.
FLD = Standard flooded lead acid industrial
type
battery curve.
CTM. = Custom curve. Uses the voltage
and
current values programmed in the
STRT A/100 A.H.,FIN. A/100A.H., GAS. V/C.,
and LID. V/C.
YGR
SLR
DSG = Sealed lead acid battery curves
SLE
DAG
CDR
MAX = Opportunity Charge Curve
*MAH will be displayed if the Multi-Amp Hour
Feature is turned on.
39. START AMPS/100
The selected output curve start current setting
(10.0 to16.3 amps per 100 ampere-hours).
40. FINISH AMPS/100
The selected output curve finish current setting
(0.0 to 7.9 amps per 100 ampere-hours).
41. GASSING V/C
The selected output curve gassing voltage level
setting (2.00 to 2.99 volts/cell).
42. LID. V/C
The selected output curve lid voltage setting
(2.00 to 2.99 volts/cell).
43. CHARGER I.D.
The battery charger identification number.
Factory setting = 0000
44.
The number of hours before the charger automati-
cally starts and refresh charges a battery that has
not been disconnected (8 to 99 hours).
Factory Setting = 72 hours.
45. DVDT DISABLE
Disables the automatic DV/DT charge termination
feature and enables Voltage Time charge
termination.
OFF = (DV/DT Mode)
ON = (VT mode)
46. PRESENT MONTH
The current month (1 to 12)
47. PRESENT DATE
The current day of the month (1 to 31).
48. PRESENT YEAR
The current year
49. MULTICELL MODE
Enables the automatic cell selection mode of
operation for the charger. When turned off, the
charger operates at the Fixed cell size (see FIX.
CELL SIZE).
50. COOL DOWN HOURS
The number of hours cool down from the end of
charge until charge complete is indicated by the
charger (0 to 8).
51. BID CELLS
If a connected battery is equipped with a Battery I.D.
module, the battery cells size (6,9,12,18,24,36) may
be reprogrammed into the BID. The control must be
in “Manual Stop” status.
52. BID NUMBER
If a connected battery is equipped with a Battery I.D.
module, the I.D. number (001-999) may be re-
programmed into the BID. The control must be in
193111-121
EC2000 CONTROL FEATURES
