122770 06 18-09-2007 67
List of Spare Parts – ATC-155 A/B
Pos. Number Spare Parts
(Compare exploded view section 3.4)
1 123125 I/O Power plate with RS232
2 123127 Display module with keyboard and PCB board
3a 123128 I/O Plate without sensor input A Models only
3b 123129 I/O Plate with sensor input B Models only
4 123130 Reference sensor
5 123132 Well, Complete without sensor
4+5 123137 Well, Complete with sensor
6 123135 Fan, Complete
7 123180 Power PCB, cooling device
8 123181 Main board without sensor input A Models only
9 123182 Main board with sensor input B Models only
10 105465 Grid plate
11 105327 Transformer
12 60G032 Rubber foot
13 105575 Cable, 30-pol
14 105576 Cable, 34-pol
15 105577 Cable, 16-pol
16* 105580 Cable, 26-pol
16* 125232 Cable, 26/34-pol
17 105581 Cable, 2-pol
- 60B315 Fuse 5AT
- 105786 Fuse 3AT
- 123690 Fuse 2.5AT
- 105783 Fuse 1.6AT
- 123187 Fuse 800mAT (F1) for Power PCB
- 123159 Fuse 5AT (F2) for Power PCB
- 123185 Fuse 315mAT (F3) for Power PCB
- 123158 Fuse 1,6AT (F4) for Power PCB
- 123160 Screw set, Complete
50-REP-EPROM 3 E-prom
