Ametek Land Cyclops 100L

Portable Thermometers
Cyclops L
WARNING
ThisproductcontainsaLithiumMetalCellincompliancewithSectionIIof
PI970.
IfyouneedtoreturnthisinstrumenttoAMETEKLandanditispossible
thatitwillbeshippedbyair,refertotheIATADangerousGoodsGuidelines
forLithiumbatteries.
TheCyclopsportablethermometerispoweredbya9VdrycellPP3battery,or
viatheUSBcableifitisconnectedtoaPC.Theactivepowersourceisindicated
ontheLCDdisplay.WhenUSBpowerisconnected,nopowerisdrawnfromthe
PP3battery.Itisrecommendedtoswitchthethermometerobeforechanging
thebatteryorinsertingtheUSBlead.Thereisalsoasmallinternalcell(Lithium
Metal)whichmaintainstheclockwhilstthebatteryisbeingchanged.ADuracell
PP36LR61/MN1604(orequivalent)batteryissuppliedwiththethermometer.
1) Beforeinsertingorchangingthebattery,switchthethermometerOFF.
2) Thebatterycoverisonthetopsurfaceof
thethermometerbody(seeFig.4-1).
Fig.4-1
Fig.4-2
THERMOMETER
POWER SUPPLY
4
User Guide4 - 0
3) Slidethecoverbacktofullyexposethe
batterycompartment(seeFig.4-2).
