Ametek Land Cyclops 100L

3 - 1
Cyclops LPortable Thermometers
User Guide
THERMOMETER
DESCRIPTION
3
Note:HeatProtectionJacket(PartNº811279)notillustrated
1 LCDdisplaypanel   9 Tripodmountinghole
2 Keypad     10 Adjustablewriststrap(inpackaging)
3 Opticalfocusingring*  11 Protectivecover
4 Protectivewindow   12 Adjustableeyepiece
5 Lenscap     13 Batterycompartmentcover
6 ON/OFFswitch   14 InternalBluetoothAntenna
7 Trigger     15 Lenshood(inpackaging)
8 USBConnector
*OpticalFocusRingisnotttedtoCyclops055LThermometers
Fig.3-1Cyclops portableinfraredthermometer
