Communications Options
M370430-01 Rev F 6-3
SETTING UP LAN/ETHERNET
This section is intended for network administrators responsible for the
configuration and maintenance of devices on the network. It provides
information for connecting and configuring the power supply with the
MEB option.
Basics
Communication Cable Requirements
Use a standard RJ-45 (see Figure 6-1) and RJ-45 cross-cable (see Figure
6-2).
Figure 6-1 Computer or HUB Plug
Figure 6-2 Power Supply Plug
Figure 6-3 RJ-45 Plug
