MODEL 227
OPERATION MANUAL
Doc # 740063 Rev E
SECTION IV - SYSTEM FUNCTIONS
4.9 GLOSSARY OF DISPLAY SYMBOLS AND ABBREVIATIONS - The M-227
displays contain many abbreviations. The following is an alphabetical listing:
AL = Aluminum
AMP = Amperes
BCK = Background (low value of a function that pulses)
CAL = Calibrate or calibration
CCW = Counterclockwise
CONT = Continuous operation
COOL = Coolant flow
CS = Carbon steel
CW = Clockwise
DLY = Delay time
EXT = External input or function
FLT = Fault
HAS = Hastaloy
INC = Inconel
INPUTAC = Input power AC voltage check
IPM = Inches per minute
LIB = Library, listing of programmed weld schedules
LVL = Level or levels
LVPS = Low voltage DC power supply check
MAT = Material
MNL = Monel
OD = Outside diameter
OK = Mean monitored function is operating properly.
PRE-PURGE-POST = PREPURGE, postpurge columns.
PRI = Primary function value
PRI-AMP-BCK = Primary amp, background amp columns
PRI-PULSE-BCK = Primary time, background time columns
PRI-RPM-BCK = Primary speed, background speed columns
PRO = Program mode
REV = Software revision or sometimes Reverse
ROT = Rotation or travel function
ROT DLY = Rotation or travel start delay time
RPM = Revolutions per minute
SP = Special material
SS = Stainless steel
SYS HOURS = System hours indicate total power-on time.
TEMP = Power supply internal temperature
TI = Titanium
# = Weld schedule number
* = Indicates that more information is available
4.17
