MODEL 227
OPERATION MANUAL
Doc # 740063 Rev E
SECTION IV - SYSTEM FUNCTIONS
4.10 GLOSSARY OF DISPLAY TERMS - The M-227 displays contain many terms that
do not relate directly to a function or sequence. The following is a listing of
those terms:
AMIWELD = Name, type and revision of software
ARC GAP = Distance needed between electrode and weld.
ARC HOURS = Total hours system has been welding.
BAD START = Problem has occurred with RF start.
CALCULATE = Function calculates RPM or tungsten length.
CANCEL = Ends step without storing or completing.
COPY = Allows a schedule to be copied with a new #.
CREATE = For creating a new weld schedule.
DATE RESET = Resets date function.
DELETE = Used to delete a weld schedule from memory.
INVALID NUMBER = Can appear by attempting to CREATE a weld
schedule that already exists or by Selecting a weld
schedule that does not exist.
MODE LOCK = Screen cannot be changed. Weld schedule (if
selected) will be locked in.
MODIFY = Used to permanently change a weld schedule.
OPERATE = Operate mode only, cannot program.
OVERRIDES = Ability to change a value temporarily.
PROGRAM/OPERATE = Ability to program or operate.
RING = Insert ring is used for filler material.
ROTOR OD = Outside diameter of M-9 rotor.
SENSOR 1,2,3 = User defined faults.
STORE = Puts weld information into memory.
TRANSFER = Allows copying of memory to another M-227 or
to the M-227-EMM.
TYPE = Describes the basic type of weld.
WALL = Wall thickness of the weld.
WARNING = Used to indicate that if step is continued a
permanent loss of information will result.
4.18
