END OF MODBUS 485 COMMUNICAITONS PROTOCOL
Function Command
(without CRC)
Action Notes
0 11 08 00 00 Echo Message Return the Exact Sames Message
1 11 08 00 01 Restart Communication Restarts from a Previous 4 Command
2 11 08 00 02 Return Error Byte Returns Same as Holding Register 23
4 11 08 00 04 Listen Only Mode Stops the Analyzer from Responding to
Anything
10 11 08 00 0A Clear All Diagnostic Counters Clear Each of the Diagnostic Counters to
Zero
11 11 08 00 0B Total Message Count Total Number of Messages Seen by the
Analyzer
12 11 08 00 0C CRC Error Count Number of CRC Errors Seen by the Ana-
lyzer
13 11 08 00 0D Exception Count Number of Invalid Modbus Commands
14 11 08 00 0E Number of Slave Messages Number of Messages the Analyzer has
Returned
15 11 08 00 0F Number of No Responses Number of Messages Addressed to the
Analyzer that It did not Respond to
16 11 08 00 10 Number of NAK Responses Number of Messages with Incorrect
Parameters (such as Invalid Registers or
Out-of-bounds Values) Seen by the
Analyzer
Table III: Diagnostic Functions
The diagnostic functions 0, 1, 2, 4, 10, 11, 12, 13, 14, 15, and 16 are supported.
Note that each counter will count up to 65535 but will not go any higher. They can be reset
to zero with the 10 command.
42
