AMI 415 - Page 11

Model 415
Operation Manual
SECTION II - SPECIFICATION
The following contains only general specifications about the M-415 Power Supply. More detailed
information is available in AMI Specification No. 415.
2.0 ELECTRICAL
1. RATING PLATE DEFINITIONS
1) Company: Country:
ARC MACHINES, INC. USA
3) Model:
Model 415
4)
S/N: DATE:
8) Process: 10) Type:
DC
23) Shock Rating:
S
6) Standards:
NEMA EW1 IEC 974-1
9) Output:
Minimum Maximum
5A / 5V 400A / 30V
11) No-load Voltage:
U
0
= 61V
12) Duty Cycle:
X = 100% ALL RATED OUTPUTS
15) Input:
3~ 50/60 HZ
18) Voltage:
U
1
= 200V
U
1
= 240V
U
1
= 400V
U
1
= 440V
U
1
= 480V
U
1
= 575V
19) Input Current:
I
1max
= 49A I
1eff
= 49A
I
1max
= 44A I
1eff
= 44A
I
1max
= 25A I
1eff
= 25A
I
1max
= 25A I
1eff
= 25A
I
1max
= 20A I
1eff
= 20A
I
1max
= 20A I
1eff
= 20A
21) Rating:
IP21
22) Rating:
G.T.A.W.
1) - Manufacturer and Country of Origin.
3) - Model Number Rating Plate applies to.
4) - Serial Number and Date of Manufacture.
6) - International and USA Standards that the equipment meets.
8) - Weld Process symbol for GTAW welding.
9) - Rated MIN and MAX Outputs at Continuous Current with no pulsation.
Rated MIN and MAX Outputs when current is pulsing.
10) - Symbol that output is Direct Current (DC) only.
11) - Rated No Load Output Voltage (open circuit voltage) is 61 volts.
12) - The M-415 is a 100 % Duty Cycle for the rated outputs (9).
15) - Input Voltage type contains symbol for three (3) phase Alternating
Current (AC) input at 50 or 60 Hz frequency.
18) - Nominal Input Voltage value is dependent on Transformer type.
M-415s manufactured before January 1999 are listed as: Domestic, or International.
After January 1999 the Universal transformer was released for use in all countries.
19) - Rated maximum current required from the AC supply. Given for both
I
1 maximum (I1max) and I1 effective (I1eff). Plate shown above is for the Universal
transformer. Consult the rating plate on your Power Supply for actual number.
21) - International Protection (IP) rating. The M-415 is rated IP21 which includes protection
against a limited amount of exposure to rain (does not make it weather proof or
intended for all weather usage).
22)- The M-415 is rated as class I. No symbol is used for class I equipment.
23)- “S” Symbol indicates a welding power source which is suitable for an environment with an
increased electric shock hazard.
Docum
e
nt No. 740084
Revision N
6
