AMI NGX MINI 2 - Page 18

22022623 Rev B 16 NGX Mini 2 Jukebox
Figure 1-C
300 W
4 Ohms
300 W
4 Ohms
300 W
4 Ohms
300 W
4 Ohms
300 W
4 Ohms
300 W
4 Ohms
75 W
4 Ohms
75 W
4 Ohms
75 W
4 Ohms
75 W
4 Ohms
75 W
4 Ohms
75 W
4 Ohms
150 W
8 Ohms
150 W
8 Ohms
75 W
4 Ohms
75 W
4 Ohms
Primary
Amplifier
Load as shown is
480 W per channel.
Maximum power capacity
is achieved.
NOTE: SPEAKER WATTAGE SHOWN
IS RATING OF SPEAKER
+ +
+ +
+
+
+
+
+
+
Load as shown is
360 W per channel.
Channel 2 +
Channel 2 -
Channel 1 +
Channel 1 -
Channel 2 +
Channel 2 -
Channel 1 +
Channel 1 -
Load as shown is
240 W per
channel
+
+
+
+
+
+
Channel 2 +
Channel 2 -
Channel 1 +
Channel 1 -
Primary
Amplifier
Primary
Amplifier
