NGX Mini 2 Jukebox 1 22022623 Rev B
Table of Contents
Important Safety Instructions ________________________________________ 2
Section A - Jukebox Specifications ___________________________________ 3
Section B - Placing the Wall-Mounted Jukebox on Location _______________ 5
Location Power and Warnings _________________________________________________ 6
Jukebox Power and Reset Switch ______________________________________________ 7
Wall Mounting Instructions ____________________________________________________ 8
IR Remote Installation Instructions ____________________________________________ 10
Testing the Unit ___________________________________________________________ 11
Lighting Controller _________________________________________________________ 12
Marquee Display __________________________________________________________ 12
Section C - Sound System Set Up ___________________________________ 13
Extension Speaker Operation ________________________________________________ 14
Selecting Speaker Power ____________________________________________________ 14
Selection Procedures____________________________________________________ 14
Extension Speakers Connected to Amplifier Channel + and – terminals ____________ 15
Amplifier Overload Check ___________________________________________________ 15
Section D - Service & Maintenance __________________________________ 19
Recommended Routine Maintenance __________________________________________ 20
Calibrating the Touchscreen _________________________________________________ 21
Hard Drive Replacement ____________________________________________________ 21
Section E - Troubleshooting ________________________________________ 23
LED Indicators ____________________________________________________________ 24
Troubleshooting Charts _____________________________________________________ 26
Connection Diagrams _______________________________________________________ 28
Section F - Parts Catalog ___________________________________________ 35
Front Door _______________________________________________________________ 36
Currency Components ______________________________________________________ 39
Currency Components ______________________________________________________ 40
Electronic Components _____________________________________________________ 41
Accessories ______________________________________________________________ 44
