AMI NGX MINI 2 - Inside Cabinet

22022623 Rev B 36 NGX Mini 2 Jukebox
Front Door
Front Door Assembly
Ref.
Qty.
Part #
Description
Ref.
Qty.
Part #
Description
1
1
61205002
Display Assy
-
18.5” HD
4
2
70093403
Cable Clamp
1a
1
61210601
Touch Glass Sensor Assy
5
1
41011
9
01
CBA
-
LED Controller, Mini 2
1b
1
40993902
Display Panel LCD 18.5”
6
2
70093402
Cable Clamp
1c
1
61205052
Power Supply
7
See page 37
Door Frame & LED Lighting
1d
1
61205061
Touch Controller
8
See page 39, 40
Curr
ency Panel
1e
1
61194756
A/D Board
9
1
34103702
Catch
-
Bottom
1f
1
61194755
OSD Board
1g
1
21121225
Power Cord
Components not shown in assembly above
1h
1
22164202
Cable
-
VGA
1
34022357
Harness Assy
-
Door
1i
1
34068706
Cable
-
USB
1
22145629
Harness Assy
-
LED Lights
2
2
3411500
1
Bracket
-
Mounting
1
34052610
Harness Assy
-
Backlight Panels
3
1
34103701
Catch
-
Top
1
22145624
Harness Assy
-
LED Controller
