AMI NGX MINI 2 - Front Door Assembly

22022623 Rev B 34 NGX Mini 2 Jukebox
NGX MINI 2 WIRING DIAGRAM (PAGE 5)
1 2 3
1
2
1
2
J6
1
2
3
1 2 3
J12
1
2
1 2 3
1
2
1 2 3
1
2
J1
1
2
1 2 3
1 2 3 1 2 3
1 2 3
1 2 3 1 2 3
1 2 3 1 2 3
B-2
LED BOARD
41024201
MARQUEE LIGHTED BACKPANEL
22325406 - DIFFUSER PANEL
34105810 - CBA - LED
LED BOARD 41024202
R-2 R
BRIGHT
34052610
22145629
41011901
R
LED BOARD 41024202
B
LED CONTROLLER
B
LED BOARD 41024202
LED BOARD
41024201
LED BOARD 41024202
AMI LIGHTED BACKPANEL
22325409 - DIFFUSER PANEL
34105809 - CBA - LED
LIGHTSHOW
SPEED
AUDIO
B-8
POWERR-5
TO AUDIO Y SPLITTER
AT CORE COMPUTER
TO ROWELINK (GREEN)
AT CORE COMPUTER
PART OF 61113311
MAIN HARNESS
B
G
R
B-2
R-2
NO SHUNTS
INSTALLED
LIGHTING STARTS IN
THE MIDDLE OF THE
LOWER LED BOARD
LIGHTING ENDS HERE
3 SHUNT JUMPERS
70080801 INSTALLED
HERE TO CONTINUE
LIGHTING
BOARDS MUST BE
INSTALLED WITH
ARROWS AS SHOWN
22145630
22145630
