22022623 Rev B 6 NGX Mini 2 Jukebox
Location Power and Warnings
The jukebox must have a clean source of properly-phased and grounded 115VAC
power at 10 amps max. This MUST be provided 24 hours a day, 7 days a week.
The outlet the jukebox is connected to must NOT be controlled by a switch, nor
should the circuit breaker feeding it be shut off at night.
If the outlet is not properly phased, grounded, or is connected to an overloaded
circuit, it must be corrected by a qualified electrician before using.
The main power distribution unit is the power supply. This device contains a 10 amp fuse with a separate ON/OFF
power switch located on the bottom of the power supply chassis.
Figure 1-B – Inside View of Cabinet
with Front Door Opened
