amiad ADI-P User Manual

ADI-P 910101-000992 / 05.20 02 Page 10 of 21
Screens Details
The Online Status screen:
The upper red line
Displays the name of the currently connected controller and the communication status.
Time from last flush
The time since the end of the last flush cycle.
Last flush cause
The trigger that initiated the last flush.
Pressures - Inlet
The current reading of the filter's inlet pressure.
Pressure - Outlet
The current reading of the filter's outlet pressure.
Pressure - DP
The pressure differential across the filter; calculated by subtracting the outlet pressure from the
inlet pressure.
Manual Flushing
Press this icon to start a manual flush cycle.
The Counters screen:
The upper red line
Displays the name of the currently connected controller and the communication status.
Last reset at:
The date of the last resetting of the counters.
DP Cycles
The number of flush cycles started due to a DP signal.
Interval Cycles
The number of flush cycles started due to the time intervals program. Also count the Antifreeze
Protection Intervals Flushes
Preset
The number of flush cycles started due to the preset daily start time and the current status of this
program.
Manual Cycles
The number of flush cycles started due to a manual start command issued by the user.
Total Flushing Cycles
The total number of flush cycles started for any reason.
Reset Button
Press this button to reset the counters to zero.
Alerts screen:
The upper red line
Displays the name of the currently connected controller and the communication status.
The second line
Enables sorting alerts between two dates and resetting an alert.
The alerts list (see
below)
Display the alert messages according to their occurrence time and date.
Alarms and faults list:
Alert
Possible cause
Recommended Action
Low battery
Low battery voltage
Replace all 4 controller batteries
Low battery pause
Controller paused due to low battery voltage
Replace all 4 controller batteries
High DP alarm
DP value is >= HDA threshold (units: bar/100)
Alert only
High DP fault
DP value is >= HDF threshold (units: bar/100)
Alert only
Continuous mode alert
Controller exceeded number of consecutive
flushes for alerts
Check configuration/check DP: If high, perform
manual flush with downstream valve closed,
open the filter for inspection
DFU failed
Firmware update fail
Validate cellular reception and try again
Out of range app
connection
Controller out of range during connection
session
Get closer to the controller with the
smartphone (within Bluetooth® range)
Sensor pressure read
failed
The number of the sensor that failed to read.
Inlet(0), Outlet(1), Piston(2)
If continues - contact support
Capacitor charger start
failed
Unable to charge capacitor
Contact support
Load capacitor timeout
Capacitor charge timeout
Check battery voltage level, contact support
Low downstream
pressure
The outlet pressure is less than 1.5 bar
Check the filter and the water system
High upstream pressure
The inlet pressure is greater than maximum
allowed pressure for the filter
Adjust the water system inlet pressure
