Set hood aside using xture no. 3.
Place a receptacle underneath the disassembled hydraulic mo-
tor. Remove shims, press out pins (381-1-4), (381-2-4) from pis-
ton ends. Using lifting hydraulic motor (381-1-14), (381-2-14)
remove from equipment, remove hydraulic lock (381-1-17),
(381-2-17).
