Ampac XP95 - Environmental Characteristics; Product Codes

9
MAN3037-2
XP95 PRODUCT GUIDE
6.3 Environmental Characteristics:
The XP95 optical smoke detector is unaffected by wind or atmospheric pressure and operates over the
temperature range -20°C to +60°C. See Fig. 10.
Figure 8 – Schematic Diagram – XP95 Optical Smoke Detector
Figure 9 – Typical Response Characteristic – XP95 Optical Smoke Detector
Figure 10 – Typical Temperature Response – XP95 Optical Smoke Detector
6.4 Product Codes
Product Description LPCB (EN54-7) SAI Global (AS7240-7) Activfire (AS1603-2)
XP95 Optical Smoke Detector
55000-620AMP 4106-2001 201-0003 (55000-630)
XP95 Optical Smoke (Black) Detector
55000-660AMP 4106-2010 201-0092 (55000-660)
