9.3 Technical Data:
Specifications are typical and given at 23°C and 50% relative humidity unless otherwise stated.
Call Point Type: Deformable element
Detection Principle:
Operation of a switch
Weight:
151g
Alarm Indicator:
Red Light Emitting Diode (LED)
Fault Indicator:
Amber/Yellow Light Emitting Diode (LED)
Type Code:
(210 43) 111 11
Supply Wiring:
Two wire monitored supply, polarity insensitive
Loop Connections:
Terminal Block L1 and L2
Operating Voltage:
17 - 28V DC
Communication
Protocol:
5-9V peak to peak
Quiescent Current:
100µA at 24V DC
Power-up Surge Current:
1mA
Maximum power up time:
1s
Alarm Current, LED on:
4mA
Normal analogue value:
16
Alarm State Value:
64
Temperature Range:
Maximum continuous operating +60°C
Minimum continuous operating 0°C
Minimum operating -20°C (no condensing/icing)
Storage -30°C to +80°C
Humidity:
0 to 95% relative humidity (no condensation)
Compliance Standard:
To EN54-11: 2001, EN54-17:2005 (isolated version)
IP Rating:
24D
Dimensions:
89mm x 93mm x 26.5mm (manual call point)
87mm x 87mm x 32mm (back box)
Material:
Housing: Red self-coloured polycarbonate/ABS
