If not in use, the Speedo Input should be connected to the 0V terminal
to prevent the input from floating.
4.4.9 Oil (Auxiliary) Input (Terminal Block 5)
The Diesel Machine Monitor is provided with an input for monitoring the voltage output of an auxiliary
sensor (typically an oil sensor). The Oil input accepts a 0-5V input and records this information in the
Diesel Machine Monitor’s log.
If not in use, the Oil Input should be connected to the 0V terminal to
prevent the input from floating.
