8 SPECIFICATIONS
Supply (Flying Lead)
Voltage
9.5 - 36Vdc
Current (Full Load)
1.4A
Supply Ripple
Tolerance
12V Supply Voltage: ±3V
12V Supply Voltage: ±12V
Max. Voltage Overload
90V for 100ms
Battery
Type
Sealed ‘Gel’ type Lead Acid
Life
Up to 5 years
Charge Cycle
Two stage, hardware/software controlled
Max. Charge Current
Limited to 420mA max
Outgassing Relief
Battery pressure valve and sintered vent on enclosure
Standby Life
3 weeks before recharge required
Charge Time to First
Use
3 hours min for 5 re-starts following 3 weeks standby
Methanometer Supply
Voltage (Full Load)
Minimum: 8.5Vdc (input supply off or battery in empty state)
Maximum: 10.8Vdc (input supply active or full battery)
Voltage (No Load)
12Vdc
Status Indicator Supply
Voltage (Full Load)
Minimum: 8.5Vdc (input supply off or battery in empty state)
Maximum: 10.8Vdc (input supply active or full battery)
Voltage (No Load)
12Vdc
Solenoid Supply
Voltage
18Vdc max. holding solenoid
Temperature Sensor Inputs
Number of Inputs
3
Type
RTD 100Ω at 0˚C
Scaling
0 to 200˚C
Excitation Current
1.0mA
Resolution
1.0˚C
Accuracy
±3˚C
Fault Modes
Open sensor up-scale
Shorted sensor down-scale
Oil Pressure Sensor Inputs
Number of Inputs
1
Type
Analogue input (0V to 5V)
Range
Application specific
Speed Input
Number of Inputs
1
Type
Digital frequency counter (0V to 5V pulse train).
