Ampcontrol EFL - Figure 4.2: Enclosure Dimensions - External Barrier; Figure 4.3: Enclosure Dimensions - EFL Relay with Internal Barrier

Ampcontrol Pty Ltd – ABN 28 000 915 542
EFL PROTECTION RELAY USER MANUAL
MAG-178 Version 5 – MARCH/2020
Uncontrolled Copy - Refer to Ampcontrol Website for Latest Version
Page 11 of 23
APPROVED FOR EXTERNAL DISTRIBUTION
– PROPERTY OF AMPCONTROL PTY LTD
– NOT TO BE REPRODUCED IN PART
Figure 4.2: Enclosure Dimensions – External Barrier
Figure 4.3: Enclosure Dimensions – EFL Relay with Internal Barrier
110
23 114
68 114
118
