Ampcontrol EFL - Figure 4.4: Terminal Numbering Arrangements for EFL Relay with External Barrier; Figure 4.5: Terminal Numbering Arrangement for EFL Relay with Internal Barrier

Ampcontrol Pty Ltd – ABN 28 000 915 542
EFL PROTECTION RELAY USER MANUAL
MAG-178 Version 5 – MARCH/2020
Uncontrolled Copy - Refer to Ampcontrol Website for Latest Version
Page 12 of 23
APPROVED FOR EXTERNAL DISTRIBUTION
– PROPERTY OF AMPCONTROL PTY LTD
– NOT TO BE REPRODUCED IN PART
4.3.3 Terminal Layouts
Figure 4.4: Terminal Numbering Arrangements for EFL Relay with External Barrier
Figure 4.5: Terminal Numbering Arrangement for EFL Relay with Internal Barrier.
1,2,3,4
13,14,15,16
9,10,11,12
25,26,27,28
17,18,19,20
21,22,23,24
29,30,31,32
Stand Alone EFL
5,6,7,8
Barrier
1,2,3,4
5,6,7,8
Ua, Ub, Uc
Flying Leads
1,2,3,4
5,6,7,8
13,14,15,16
9,10,11,12
Ua, Ub, Uc
Flying Leads
EFL with Internal Barrier
25,26,27,28
17,18,19,20
21,22,23,24
