BA Series Bass Guitar Combo
10
BA-108 TECHNICAL SPECIFICATIONS
Output Power Rating 15 watts @ 4 ohms, 10% THD+N
Signal to Noise Ratio 77 dB (20 Hz–20 kHz, unweighted)
Maximum Gain @ 1 kHz Input: 53 dB
Aux input: 44 dB
Tone Controls Bass: +18/–20 dB @ 40 Hz
Mid: +14/–15 dB @ 500 Hz
Treble: +14/–15 dB @ 4 kHz
Speaker Specs 1 x 8" speaker: 4 ohms
Maximum Operating Range 40 ˚C ambient temperature, 93% relative humidity,
up to 2000 m altitude
Power Requirements 100 VAC~ 50/60 Hz, 25W
120 VAC~ 60 Hz, 25W
220 VAC~ 50/60 Hz, 25W
240 VAC~ 50/60 Hz, 25W
Size (H x W x D) 16.8 in x 15.0 in x 12.0 in
427 mm x 381 mm x 305 mm
Weight 28 lb / 12.7 kg (approximately)
INPUT
POWER
AMPLIFIER
VOLUME
BASS
MIDRANGE
TREBLE
TONE CONTROL CIRCUITRY
15 W
MUTE
8” WOOFER
4 OHM
AUX Inputs
PHONES
AUX LEVEL
Mono 1/4”
STEREO 1/8”
Stereo1/8”
LIMITER
