www.ampeg.com
©2001 AMPEG, 1400 Ferguson Avenue, St. Louis, MO 63133 U.S.A.
TECHNICAL SPECIFICATIONS:
OUTPUT POWER RATING 100 Watts at 4 ohms
MAX INPUT LEVELS 0dB Input: 1.75V RMS
-15dB Input: 9.75V RMS
CD Input: 5V RMS
LINE OUT LEVEL 120mV RMS
HEADPHONE OUT LEVEL 3.75V RMS
GAIN 39dB
STYLE 1 = -25dB @500Hz
2 = -12dB @500Hz
3 = flat
4 = +5dB @2kHz and above
5 = -6dB @50Hz and below
TREBLE 40dB range @10kHz
ULTRA MID 30dB range @500Hz
BASS 36dB range @50Hz
SPEAKER SPECS 15”, 150 w, 4 ohm, 2.5” voice coil dia., 56 oz. magnet;
Piezo tweeter
POWER REQUIREMENTS 120VAC, 60Hz, 70VA
100/115VAC, 50/60Hz, 70VA
230VAC, 50/60Hz, 70VA
SIZE AND WEIGHT 21” W x 21” H x 15-1/2” D; 62 lbs.
Ampeg continually develops new products, as well as improves existing ones. For this reason,
the specifications and information in this manual are subject to change without notice.
47-054-04 • 011206
SYSTEM BLOCK DIAGRAM:
BA115 BASS AMPLIFIER
